UN-AT16014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT25014C-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT35014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT50014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-TFA2518X-12MP
| Taurus シリーズ4/3インチフォーマット FA レンズ ( 12 MP) |
|||||
| モデル |
UN-TFA2518X-12MP |
||||
| 焦点距離 |
25mm _ |
|
|||
| 絞り |
F2.0 ～F22 |
||||
| 画像フォーマット |
4/3インチ(23mm) |
||||
| マウント |
C |
||||
|
画角 奥行き×高さ×奥行き(°) |
|
4/3インチ |
1インチ |
1/2" |
|
| D |
49.8 ° |
35.8 ° |
18.3 ° |
||
| H |
40.6 ° |
28.9 ° |
14.6 ° |
||
| V |
31.1 ° |
21.8 ° |
11.1 ° |
||
| 光学歪み |
-0.64%@ y=11.5mm |
-0.48%@ y=8.0mm |
-0.15%@ y=4.0mm |
||
| モッド |
0.15m |
||||
| 寸法 |
Φ47.3 × 82.7mm _ _ |
||||
| バック焦点距離 |
22mm |
||||
| 設計波長 |
420~1000nm |
||||
| 手術 |
マニュアルアイリス |
||||
| マニュアルフォーカス |
|||||
| フィルタースレッド |
M46.0×P0.75 |
||||
| 重さ |
248g _ |
||||
| 作業温度_ |
-20℃ ～+60℃ |
||||
| |
|||||
UN-GSWIR1614C
| Ge min iシリーズSWIRレンズ |
|||
| モデル |
UN-GSWIR 16 14C |
||
| 焦点距離 |
16mm _ |
|
|
| 絞り |
F1.4 _ |
||
| 画像フォーマット |
1インチ |
||
| マウント |
C |
||
| 画角 |
|
1インチ |
|
| D |
54 ° |
||
| H |
43.8 ° |
||
| V |
33.4 ° |
||
| 光学歪み |
< -0.6 % |
||
| モッド |
0.3m _ |
||
| 寸法 |
Φ54 * 63.00mm _ _ |
||
| フランジBFL |
1 7。5 26mm |
||
| 後焦点距離_ _ |
13.72mm |
||
| 解決 |
80lp /mm |
||
| 手術 |
マニュアルアイリス |
||
| マニュアルフォーカス |
|||
| 設計波長 |
900～1700nm |
||
| フィルタースレッド |
M52x0.75 |
||
 |
|||
