| Taurus シリーズ1.1インチフォーマット FA レンズ ( 12 MP) |
||
| モデル |
UN-TFA122 8L -12MP |
|
| 焦点距離 |
12mm _ |
|
| 絞り |
F2.8 _ |
|
| 画像フォーマット |
1.1インチ |
|
| マウント |
C |
|
| 画角 奥行き×高さ×奥行き(°) |
|
1.1インチ |
| D |
72.26 ° |
|
| H |
60.46 ° |
|
| V |
47.26 ° |
|
| 光学歪み |
≤ 0.5% |
|
| モッド |
0.10m _ |
|
| 寸法 |
Φ51 ×61.04 |
|
| フランジBFL |
1 7。5 26mm |
|
| 後焦点距離_ _ |
9.13mm |
|
| 手術 |
マニュアルアイリス |
|
| マニュアルフォーカス |
||
| 設計波長 |
400～900nm |
|
| フィルタースレッド |
M 49×0.75 |
|
UN-TFA2520L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA3520L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA5020L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA2524L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible 1.2" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA0628S-6MP
Product Features:
· Developed for 1/1.8" image format
· Low distortion
· High relative illumination
· Focus and iris fixed with screw
Product information: Custom designs are available upon request.
